| Specifications | ||
|---|---|---|
| work table size | mm | 1270 x 254 |
| t-slot | 3 | |
| width of t-slot | mm | 14 |
| x travel | mm | 650 |
| y travel | mm | 350 |
| z travel | mm | 110 |
| manual travel of table (z axis) | mm | 400 |
| spindle nose | ISO40 | |
| spindle speed | rpm | 65-4500 |
| spindle power | kw | 3.75 |
| position accuracy | mm | +/- 0.01 |
| reposition accuracy | mm | +/- 0.015 |
| net weight | kg | 1800 |
| machine size | mm | 1700 x 1800 x 2300 |
